Specifications
|
Printing method
|
Piezo-ceramics-driven
drop-on-demand type
|
Nozzle alignment
|
128 nozzles, 1 hole/nozzle
|
32 nozzles, 1 hole/nozzle
|
Maximum printing area
|
Height 1~64.5mm(with
the head turned and semi-fixed)
|
Height 1~40.0mm(with
the head turned and semi-fixed)
|
Width ~7620mm(with
the head in the vertical position and horizontal scaling at 100%) (varies with printing conditions)
|
Ink ejection direction
|
Horizontal/Downward
|
Horizontal/Downward/Upperward
|
Printable surfaces
|
Cardboard, paper, wood, and other porous materials
|
Maximum printing speed
|
152 m/min. (Darkness Level 1) ~ 76 m/min. (Darkness Level 2)
|
No. of print heads
|
1~4(Maximum
head cable length: 20 m)
|
Box position detection
|
Built-in photoelectric sensor on the head, external
photoelectric sensor, external contact input
|
Restrictions on the number
of lines
|
None
|
No. of storable messages
|
999 messages/head max. (depends on the CF card memory
size)
|
Character type
|
Alphanumeric characters,
Hiragana, Katakana, JIS 1st/2nd level Chinese characters
|
Font
|
Gothic, Mincho, OCR
characters, European characters, 1 ~128 dots
|
Time/Date printing
|
Year (Western/Japanese), Month, Date, Time (24H/12H),
Minute, Second, Day, Week number, Date number, AM/PM
|
Offset setting, Character justification function
|
Number printing
|
8 digits max., Numbering in ascending/descending
order, Repetitive numbering, Incremental numbering, Zero suppress,
1-byte/2-byte character option
|
Barcode
|
ITF,CODE39,JAN,QR
|
ITF,CODE39
|
Graphics
|
BMP files, straight lines, rectangles, circles
|
Input/output interface
|
PCMCIA(TYPEⅡ),Ethernet(10Base-T/100Base-TX),RS232C/422, Exclusively designed
I/O, Encoder (Line receiver)
|
Operating environment
|
5~35゚C 10~80%RH(non-condensing)
|
Power supply
|
AC100V±10% 50/60Hz 300W(MAX)
|
Grounding
|
Class-D
|
